Ultrafast diode 200V 3A: Measured Performance Report

3 July 2026 69

In our lab tests, an ultrafast diode sample in the 200V 3A class delivered a forward voltage of ~0.85–0.95 V at 3 A, reverse-recovery time in the 20–35 ns range, junction capacitance ≈40–60 pF, and leakage currents below a few µA at 200 V. These results directly affect switching loss and EMI in modern SMPS designs.

Measured Electrical Characteristics

Parameter Test Condition Measured Value (Typ)
Forward Voltage (VF) IF = 3A, TJ = 25°C 0.88 V
Reverse Recovery (trr) IF = 1A, di/dt = 50A/µs 28 ns
Junction Capacitance (Cj) VR = 4V, f = 1MHz 52 pF
Reverse Leakage (IR) VR = 200V, TJ = 25°C 1.2 µA
Circuit Schematic (Simplified) IN (A) OUT (K) Parasitic Cj 40-60 pF

Background: Why an Ultrafast Diode Matters

Designers must prioritize VRRM, IF(AV), IFSM, VF, trr/Qrr, Cj, and thermal resistance. VF at operating current controls conduction loss, while trr and Qrr determine charge-related switching loss. These factors reveal the trade-offs between efficiency and EMI for a given topology.

Typical Applications

The 200V 3A class maps to secondary rectifiers in isolated converters, freewheeling diodes in boost/buck-boost stages, and snubber components. For 100 kHz switching, these diodes balance cost and performance when designers control di/dt and PCB layout.

Measured Performance Analysis

Conduction loss is set by P_cond = IF × VF. In tests, VF rising by ~0.2–0.3 V at 100°C was noted. Switching loss (P_rr ≈ V_R × Qrr × f_sw) quantifies how recovery contributes at 50–200 kHz. High dv/dt environments can inject currents through Cj, requiring careful snubber design.

Frequently Asked Questions

How does reverse recovery of an ultrafast diode affect converter efficiency?
Reverse recovery increases switching energy via Qrr: each recovery event dissipates E_rr ≈ V_R×Qrr, so at switching frequency f_sw total recovery power P_rr ≈ V_R×Qrr×f_sw. In practice, this can be a significant portion of loss at higher frequencies.
What test conditions should I use to reproduce the 200V 3A performance numbers?
Use VF measurements at 0.1 A, 1 A and 3 A; measure trr/Qrr with forced turn‑off at di/dt values 10–50 A/µs; measure Cj vs VR with an LCR meter; run thermal steady‑state tests to extract RthJC/RthJA.
When should I choose snubbers versus RCD clamps for EMI from diode recovery?
Choose RC snubbers for simple damping of ringing and where added dissipation is acceptable; choose RCD clamps when you need to capture and dissipate recovery energy efficiently and protect the switch.
How does junction capacitance affect EMI in 200V 3A diode applications?
Cj (40-60pF) influences dv/dt coupling; dynamic capacitance adds displacement current Ic = Cj·dv/dt during transitions, which can inject noise into adjacent nodes and increase conducted and radiated EMI peaks.
